Description
The page contains the following boxes:
● Base Bridge Mode
Note
Changing Base bridge mode
Note the section "Changing Base bridge mode" in this chapter. This section describes how
a change affects the existing configuration.
Select the required mode from the drop-down list. The following modes are possible:
– 802.1Q VLAN Bridge
Sets the mode "VLAN-aware" for the device. In this mode, VLAN information is taken into
account.
– 802.1D Transparent Bridge
Sets the mode "VLAN-unaware" for the device. In this mode, VLAN tags are not taken
into account or changed but are forwarded transparently. In this mode, you cannot create
any VLANs. Only a management VLAN is available: VLAN 1.
● VLAN ID
Enter the VLAN ID in the "VLAN ID" input box.
Range of values: 1 ... 4094
The table has the following columns:
● Select
Select the row you want to delete.
● VLAN ID
Shows the VLAN ID. The VLAN ID (a number between 1 and 4094) can only be assigned
once when creating a new data record and can then no longer be changed. To make a
change, the entire data record must be deleted and created again.
● Name
Enter a name for the VLAN. The name only provides information and has no effect on the
configuration. The length is a maximum of 32 characters.
Configuring with Web Based Management
4.7 "Layer 2" menu
SCALANCE S615 Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C388-08 217
