● Edge Type
Shows the type of the connection. The following values are possible:
– Edge Port
There is an end device at this port.
– No Edge Port
There is a spanning tree or rapid spanning tree device at this port.
● P.t.P. Type
Shows the type of point-to-point link. The following values are possible:
– P.t.P.
With half duplex, a point-to-point link is assumed.
–
Shared Media
With a full duplex connection, a point-to-point link is not assumed.
4.4.15 VRRPv3 Statistics
Introduction
This page shows the statistics of the VRRPv3 protocol and all configured virtual routers.
Configuring with Web Based Management
4.4 "Information" menu
SCALANCE S615 Web Based Management
106 Configuration Manual, 11/2019, C79000-G8976-C388-08
