Configurable function Maximum number
Security Users 30
(incl. user preset in the factory "admin")
Groups 32
Roles 32
(incl. the predefined roles)
RADIUS server 4
Firewall IP protocols:16
IP services: 32
ICMP services:16
IP rules: 128
User-specific firewall:
● Maximum number: 8 rule sets
● Parallel user access: 4
● Maximum of 128 IP rules per firewall rule set
IPsec VPN 20
You can create a maximum of 20 phase 2 con‐
nections per phase 1 (remote endpoint).
Only with IKEv2:
● Multiple subnets per phase 2 connection;
maximum 5
OpenVPN Connections: 5
Remote end points: 25
1.6 Configuration limits for SINEMA RC
Maximum overall data transfer for all devices: 800 Mbps
Maximum number of devices and users connected simultaneously: 1024 devices with 1 subnet
each
User/device combinations can be freely selected up to the maximum overall quantity structure.
As the number of subnets is also dependent on the communication relationships permitted
among one another, for example, these must be checked/questioned and restricted, where
necessary. If devices do not need to communicate with one another, this function should be
disabled to ensure optimum device behavior.
If the devices are to communicate with each other, the maximum number of devices and users
connected simultaneously is: 200 devices with 8 subnets each communicating with each other
Description
1.6 Configuration limits for SINEMA RC
SCALANCE S615 Web Based Management
Configuration Manual, 11/2019, C79000-G8976-C388-08 21
