A.2 Parameters in Syslog messages
The Syslog messages can contain the following parameters:
Parameter Description Possible values or example
ip address IPv4 or IPv6 address IP address according to
RFC1035 or RFC4291 Sec‐
tion 2.2
src port
dest port
Port that is shown as decimal number.
Format: %d
0 ... 65535
dest mac
src mac
MAC address
Format: %02x:%02x:%02x;%02x:%02x:%02x
00:0C:29:2F:09:B3
protocol Name of the service that has generated this event
or of the Layer 4 protocol used.
Format: %s
Possible entries of:
UDP | TCP | WBM | Telnet |
SSH | TFTP | SFTP
group String that identifies the group based on its name
Format: %s
it-service
user name String that identifies the authenticated user based
on his/her name
without spaces
Format: %s
maier
action user name Identifies the user based on his/her name This is
not the authenticated user.
Format: %s
Peter.Maier
role Symbolic name for the group role
Format: %s
Administrator
time minute
timeout
Number of minutes
Format: %d
44
failed login count Number of failed logins
Format: %d
10
max sessions Number of sessions
Format: %d
10
trigger pin String for an IO pin that triggers the event
without spaces
Format: %s
DI1
firewall rule String for a firewall rule
with spaces
Format: %s
Rule1
subject String for the subject in the certificate. Used as part
of the certificate-based authentication
with spaces and must also include Unicode char‐
acters
Format: (% S) or (% S% S) for UTF8 code.
(Peter Maier)
config detail String for the configuration
with spaces
Format: %s
OpenVPN
connection name Name of the VPN connection to_Baugruppe1
Appendix A
A.2 Parameters in Syslog messages
SCALANCE S615 Web Based Management
304 Configuration Manual, 11/2019, C79000-G8976-C388-08
