4.8.4 VRRPv3
4.8.4.1 Router
Introduction
Using the "Create" button, you can create new virtual routers. A maximum of 2 virtual routers
can be configured. You can configure other parameters on the "Configuration" tab.
Note
● You can use VRRPv3 on VLAN interfaces.
Requirement
For the incoming packets to be forwarded to the device, enable the predefined IPv4 rule
"VRRP".
Description
The page contains the following:
● VRRPv3
Enable or disable routing using VRRPv3.
● Reply to pings on virtual interfaces
When enabled, the virtual IPv4 addresses also reply to the ping.
● VRID-Tracking
Enable or disable VRID tracking.
When enabled, all VRRP instances are monitored. If the status of a VRRP instance changes
to "Initialize", the priority of all VRRP instances is reduced to the value "1".
If the status of a VRRP instance changes, the original priority of all VRRP instances is
restored.
Configuring with Web Based Management
4.8 "Layer 3" menu
SCALANCE S615 Web Based Management
244 Configuration Manual, 11/2019, C79000-G8976-C388-08
