Configuring with Web Based Management
4.3 "Information" menu
SCALANCE SC-600 Web Based Management (WBM)
112 Configuration Manual, 10/2021, C79000-G8976-C475-03
• MAC Auth. Port Status
Shows the status of the MAC authentication for the port. The following options are
possible:
– -
MAC authentication was disabled for the port.
– Individual
MAC authentication is configured for the port. Clients can be authenticated
individually with their MAC address.
– Blocked
MAC authentication is configured for the port. Clients are not authenticated
individually. The first client that is authenticated opens the port for all clients. No
client is authenticated yet.
– Open
MAC authentication is configured for the port. Clients are not authenticated
individually. The first client that is authenticated opens the port for all clients. The
port was opened after successful authentication of a client.
• MAC Auth. Actual Allowed Addresses
Shows the number of nodes that are allowed access after successful MAC
authentication.
• MAC Auth. Actual Blocked Addresses
Shows the number of nodes that are allowed access after failed MAC authentication.
4.3.15.6 MAC Authentication
This page shows the MAC addresses for which MAC authentication was performed.
