Siemens SIMATIC NET SCALANCE SC-600 Configuration Manual

Configuring with Web Based Management
4.4 "System" menu
SCALANCE SC-600 Web Based Management (WBM)
206 Configuration Manual, 10/2021, C79000-G8976-C475-03
Note
Automatic adaptation due to PROFINET configuration
When establishing a PROFINET connection, the setting of the combo port media type
is adapte
d automatically:
•
If a pluggable transceiver is configured, the combo port media type will be set to
"sfp".
•
If the built-in RJ-45 port is configured, the combo port media type will be set to
"rj45".
So that the automatic adaptation can be made, the
combo port media type must be
set to "auto".
Configure the combo port media type accordingly using the WBM or CLI.
• OperState
Displays the current operational status. The operational status depends on the
configured "Status" and the "Link". The following options are possible:
– Up
You have configured the "enabled" status for the port and the port has a valid
connection to the network.
– Down
You have configured the "disabled status " or "Link down" for the port or the port
has no connection.
– not present
With modular devices, this status is displayed when, for example, no media module
is inserted.
• Link
Shows the physical connection status to the network. The following options are
possible:
– Up
The port has a valid link to the network, a "link integrity signal" is being received.
– Down
The link is down, for example because the connected device is turned off.
