Configuring with Web Based Management
4.3 "Information" menu
SCALANCE SC-600 Web Based Management (WBM)
80 Configuration Manual, 10/2021, C79000-G8976-C475-03
displayed on a page is limited. Click the "Next" button to page down through the data
records.
Page back with "Prev"
On WBM pages with a lot of data records, the number of data records that can be
displayed on a page is limited. Click the "Prev" button to page back through the data
records.
Delete the display with "Clear"
In pages with sequence logs, you can delete all table entries at the same time regardless
of whether filters are selected. The display is cleared in this process. The restart counter
is only reset after you have restored the device to the factory settings and restarted the
device.
Click the "Clear" button to completely delete the data record.
Button "Show all"
You can show all entries in pages with a large number of data records. Click "Show all"
to display all entries on the page.
Note that displaying all messages can take some time.
Drop-down list to change page
In pages with a large number of data records, you can navigate to the desired page. From
the drop-down list, select the relevant page to display it.
"Reset Counters" button
Click "Reset Counters" to reset all counters. The counters are reset by a restart.
Logout
You can log out from any WBM page by clicking the "Logout" link.
Messages
If you have enabled the "Automatic Save" mode and you change a parameter the
following message appears in the display area "Changes will be saved automatically in x
seconds. Click 'Write Startup Config' to save the changes immediately."
Note
Interrupting the save
Saving starts only after the timer in the message has elapsed. How long saving takes
depends on
the device.
During the save, the message "Saving configuration data in progress. Please do not
switch off the device." is displayed.
Do not switch off the device immediately after the timer has elapsed.
