Hardware
and Installation User Manual
INDEX
A
AUX
Function
AUX 10, 3-9, 3-12, 5-7, 5-15
AUX 1
1, 5-6, 5-15
AUX 12, 3-9, 3-12, 5-6, 5-15
AUX 20, 5-6
AUX 25, 5-6
AUX 29, 5-5, 5-15
AUX 84, 4-1, 4-8, 4-12
T
roubleshooting with, 5-5–5-7, 5-15
B
Base Assembly
Installation, 3-2
Models, 3-1
Slots
Controller, 3-27
I/O Modules, 3-29
Power Supply
, 3-25
Base Number Dipswitch, TI535, 3-10, 3-13
Base, Logical, 3-13, 3-19
Battery
Backup Dipswitch
TI525, 3-5, 3-7
TI535, 3-10, 3-14
Information Protected, 1-9, 3-7, 3-14
Installation, 3-17
Baud Rate
TI525, 3-5, 3-6
TI535, 3-10, 3-15
Boolean Symbolic Code, 1-1, 1-8
C
Communication Ports
Baud Rate
TI525, 3-5, 3-6
TI535, 3-10, 3-15
Pinout, 3-28
Configuration
TI525, 3-5–3-9
TI535, 3-10–3-15
D
Diagnostics.
See
Status Word, AUX Function,
Troubleshooting
Dipswitches
TI525
Battery Enable, 3-5, 3-7
Baud Rate, 3-5, 3-6
Memory Protect, 3-8
Preset (download/retain), 3-5, 3-9
TI535
Battery Enable, 3-10, 3-14
Baud Rate, 3-10, 3-15
Highest–Numbered Base, 3-10, 3-13
Memory Protect, 3-16
Preset (download/retain), 3-10, 3-12
Distributed Base, 1-3, 3-21
Distributed Base Controller (DBC), 1-3, 3-21,
3-32
Distributed I/O, 1-3, 3-21
E
Electrical Noise
Definition, B-5
Isolation, B-7
Suppression, B-6
Emergency Stop Switch, 2-5
Enclosures, 2-6
EPROM/EEPROM
AUX Function 84 and, 4-1, 4-8, 4-12
Installation, 4-6
Jumper Pins, 4-4–4-9, 5-17
Operation At Power Up, 4-2
Programming, 4-8
Status W
ords and, 4-10
T
roubleshooting, 4-9–4-1
1, 5-17
Errors.
See
Fatal Errors, Status W
ords
