INSTALLATION
3-24
Hardware
and Installation User Manual
Complete
the following steps to insert the modules into the base.
1. Disable all user
-supplied power before inserting modules.
2. Holding
the module by the bezel, position the printed circuit board in
the upper and lower card guides.
3.
Insert the module and push until it is plugged into the backplane
connector
. The bezel should be tight against the base.
4. The bezel screws provide the ground. Use a flat-blade screwdriver to
tighten the screws at the top and the bottom of the bezel. Do not
over-tighten.
The maximum torque that can be applied to the screw is 3
Kg
–cm
(2.60 in–lb).
For instructions on wiring I/O modules and
calculating I/O power requirements, check the
appropriate
manual for each I/O module.
Complete the following steps to remove the modules into the base.
1. Disable
line and user
-supplied power
.
2. Loosen
the screws at the top and bottom of the bezel.
Prior
to removing I/O modules, you may remove the
wiring terminal block without disturbing field
wiring. Use a Phillips-head screwdriver to remove
the screws at the top and bottom of the terminal
block
and pull the terminal block off the bezel.
3. Grasp
the bezel screws and carefully remove the module. Y
ou may find
it
easier to loosen the module first by gently pulling the module up and
down
within the slot by the bezel screws.
