All permissible and/or necessary combinations of the LED are listed in the following
table.
The meaning of the symbols used in the table is as follows:
1 = LED on
0 = LED off
0.5/1 = LED flashes (0.5 Hz)
2/1 = LED flashes (2 Hz)
l = LED flickers
 = Running indicator
x = LED may illuminate
Table 3-14 Summary of LED displays
LED display
Function
SF
(red)
5 VDC
(green)
RUN
(green)
STOPU
(yellow)
STOP
(yellow)
BUS1F
(red)
BUS2F
(red)
Ramp-up 1 1 1 1 1 1 1
STOPU  RUN x 1 2/1 1 0 x x
RUN x 1 1 0 0 x x
RUN  STOPU x 1 1 2/1 0 x x
STOPU x 1 0 1 0 x x
STOPU  STOP x 1 0 1 2/1 x x
STOP x 1 0 0 1 x x
STOP  STOPU x 1 0 2/1 1 x x
Power supply is ready for operation x 1 x x x x x
Writing to Micro Memory Card
(Copy RAM to ROM)
x 1 0 0 l x x
Formatting the Micro Memory Card x 1 0 l 0 x x
Request an overall reset by the
C230-2 or via the C230-2’s mode
selector
x 1 0 0 0.5/1 x x
Overall reset in progress 1 1 1 1 1 1 1
Overall reset completed x 1 0 0 1 x x
SIMOTION kernel update is run-
ning
 1     
SIMOTION kernel update com-
pleted
x 1 0 0 1 x x
C230-2 is operating correctly 0 1 x x x 0 0
An interrupt which can be acknowl-
edged (alarm, message, note) is
present
1 1 x x x x x
