Wiring
6-93
E Siemens AG, 2003 All rights reserved
SIMOTION C230-2, 04.2003 Edition
Proceed as follows:
1. Insert the Sub-D connector (9-pin) into the drive unit.
2. Open the front cover of the C230-2 and insert the Sub-D connector (9-pin) into
the X8/X9 socket.
3. Lock the connector using the finger screws. Close the front cover.
Connecting cable
Please see Chapter 7 on “Networking” for details about the bus cable, bus connec-
tor and installation.
Note
The maximum cable length is 100 m.
The terminating resistor must be switched in (switch position “On”) at the begin-
ning and end of the bus segment. See Fig. 7-2.
Mixed operation of drives at the onboard drive interface and at the PROFIBUS DP
Drives with analog and digital connections can be operated together.
Proceed as described for the connection of drives to the onboard drive interface or
PROFIBUS DP.
