Table 10-46 PM240-2, IP20, frame size E, 200 V … 240 V 3 AC
Article No. without filter 6SL3210-1PC28-0UL0 6SL3210-1PC31-1UL0
LO base load power 22 kW 30 kW
LO base load input current 76 A 98 A
LO base load output current 80 A 104 A
HO base load power 18.5 kW 22 kW
HO base load input current 71 A 83 A
HO base load output current 68 A 80 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3830 (100 A)
100 A
3NA3836 (160 A)
150 A
Power loss 0.92 kW 1.28 kW
Required cooling air flow 83 l/s 83 l/s
Weight 26 kg 26 kg
Table 10-47 PM240-2, PT, frame size E, 200 V to 240 V 3 AC
Article No. without filter 6SL3211-1PC31-1UL0
LO base load power 30 kW
LO base load input current 98 A
LO base load output current 104 A
HO base load power 22 kW
HO base load input current 83 A
HO base load output current 80 A
Fuse according to IEC
Fuse according to UL, class J
3NA3836 (160 A)
150 A
Power loss 1.28 kW
1)
Required cooling air flow 83 l/s
Weight 29 kg
1)
approx. 1.1 kW through the heatsink
Technical data
10.6 Technical data, PM240-2 Power Module
Converter with the CU230P-2 Control Units
