Table 10-48 PM240-2, IP20, frame size F, 200 V … 240 V 3 AC
Article No. without filter 6SL3210-1PC31-3UL0 6SL3210-1PC31-6UL0 6SL3210-1PC31-8UL0
LO base load power 37 kW 45 kW 55 kW
LO base load input current 126 A 149 A 172 A
LO base load output current 130 A 154 A 178 A
HO base load power 30 kW 37 kW 45 kW
HO base load input current 110 A 138 A 164 A
HO base load output current 104 A 130 A 154 A
Fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NA3140 (200 A)
175 A
3NA3140 (200 A)
200 A
3NA3142 (224 A)
250 A
Power loss 1.38 kW 1.72 kW 2.09 kW
Required cooling air flow 153 l/s 153 l/s 153 l/s
Weight 57 kg 57 kg 57 kg
Table 10-49 PM240-2, PT, frame size F, 200 V to 240 V 3 AC
Article No. without filter 6SL3211-1PC31-8UL0
LO base load power 55 kW
LO base load input current 172 A
LO base load output current 178 A
HO base load power 45 kW
HO base load input current 164 A
HO base load output current 154 A
Fuse according to IEC
Fuse according to UL, class J
3NA3142 (224 A)
250 A
Power loss 2.09 kW
1)
Required cooling air flow 153 l/s
Weight 60 kg
1)
approx. 1.9 kW through the heatsink
