Siemens SINAMICS Series User Manual

Type spectrum, ordering information
2.2 Key for the device article numbers
SINAMICS DCM DC Converter
28 Operating Instructions, 12/2018, A5E34763375A
2.2
Key for the device article numbers
①
6RA defined according to the general guidelines for MLFB
②
Device version
23: SIMOREG compact unit, 4th generation analog
24: SIMOREG compact unit, 4th generation digital
70: SIMOREG DC MASTER
80: SINAMICS DCM
③
Rated DC currents and cooling
Natural air cooling, ambient temperature +45 °C
00: -
01: ≥ 3.6.... < 4.1
02: ≥ 4.1.... < 4.65
03: ≥ 4.65.. < 5.25
04: ≥ 5.25.. < 6.0
05: ≥ 6.0.... < 6.8
06: ≥ 6.8.... < 7.75
07: ≥ 7.75.. < 8.8
08: ≥ 8.8.... < 10.0
09: -
10: ≥ 10.0... < 11.5
11: ≥ 11.5... < 13.0
12: ≥ 13.0... < 14.5
13: ≥ 14.5... < 16.5
14: ≥ 16.5... < 19.0
15: ≥ 19.0... < 21.5
16: ≥ 21.5... < 24.5
17: ≥ 24.5... < 28.0
18: ≥ 28.0... < 31.5
19: -
20: ≥ 31.5... < 36.0
21: ≥ 36.0... < 41.0
22: ≥ 41.0... < 46.5
23: ≥ 46.5... < 52.5
24: ≥ 52.5... < 60.0
25: ≥ 60.0... < 68.0
26: ≥ 68.0... < 77.5
27: ≥ 77.5... < 88.0
28: ≥ 88.0... < 100
29: -
30: ≥ 100... < 115
31: ≥ 115... < 130
32: ≥ 130... < 145
33: ≥ 145... < 165
34: ≥ 165... < 190
35: ≥ 190... < 215
36: ≥ 215... < 245
37: ≥ 245... < 280
38: ≥ 280... < 315
39: -
40: -
41: -
42: -
43: -
44: -
45: -
46: -
47: -
48: -
49: -
Forced ventilation, ambient temperature +35 °C. With 6RA70 and 6RA80 +40 °C.
50: -
51: -
52: -
53: -
54: -
55: -
56: -
57: -
58: -
59: -
60: ≥ 31.5... < 36.0
61: ≥ 36.0... < 41.0
62: ≥ 41.0... < 46.5
63: ≥ 46.5... < 52.5
64: ≥ 52.5... < 60.0
65: ≥ 60.0... < 68.0
66: ≥ 68.0... < 77.5
67: ≥ 77.5... < 88.0
68: ≥ 88.0... < 100
69: -
70: ≥ 100... < 115
71: ≥ 115... < 130
72: ≥ 130... < 145
73: ≥ 145... < 165
74: ≥ 165... < 190
75: ≥ 190... < 215
76: ≥ 215... < 245
77: ≥ 245... < 280
78: ≥ 280... < 315
79: -
80: ≥ 315... < 360
81: ≥ 360... < 410
82: ≥ 410... < 465
83: ≥ 465... < 525
84: ≥ 525... < 600
85: ≥ 600... < 680
86: ≥ 680... < 775
87: ≥ 775... < 880
88: ≥ 880... < 1000
89: -
90: ≥ 1000... < 1150
91: ≥ 1150... < 1300
92: ≥ 1300... < 1450
93: ≥ 1450... < 1650
94: ≥ 1650... < 1900
95: ≥ 1900... < 2150
96: ≥ 2150... < 2400
97: ≥ 2400... < 2850
98: ≥ 2850... < 3250
99: -
④
Thyristor design and fuse design
⑤
Rated supply voltage
0: Control Units without power unit
1: USA Power
2: USA Base
3: Disc-type thyristors, made in China
4: Disc-type thyristors with fuse construction
5: Thyristor modules, made in China
6: Thyristor modules
7: Rated DC current in acc. with
③ × 100
8: I IS
A: -
B: 230 V
C: -
D: 400 V
E: -
F: 440 V - 480 V
G: 500 V - 575 V
H: 660 V
K: 690 V - 750 V
L: 830 V
M: 950 V
