Siemens SINUMERIK 802D

PLC diagnostics
13.2 Operating options
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
365
This softkey can be used to select the list of the PLC program blocks.
Figure 13-6 Select the PLC program block
Using this softkey will display the following properties of the selected program block:
● Symbolic name
● Author
● Comments
Figure 13-7 Properties of the selected PLC program block
Selecting this softkey displays the table of local variables of the selected program block.
3URJUDP
EORFN
3URSHU
WLHV
/RFDO
YDULDEOHV
