Define
4.2 Create new tool
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
43
Technological data
By means of the technological data, the wheel type dependent dressing technology is
defined.
Figure 4-8 Technology example data for a vertical wheel with back-slope
Dresser
Use the "1st dresser", "2nd dresser" or "3rd dresser" softkeys to access the dialog box for
entering or verifying the dresser data.
Figure 4-9 Fixed dresser
7HFKQR
ORJ\GDWD
VW
GUHVVHU
