7. Select the valid backup using the cursor keys.
8. Press the <Input> key to confirm your selection.
9. The following message briefly appears: "Starting software update"
Then the screen goes dark for several seconds.
10.If a valid backup has been found, the following message is output:
If a valid backup was not selected, then the upgrade is canceled with the following message:
"Image file is corrupt!"
In this case, switch-off the control, withdraw the data carrier and repeat the procedure by
selecting a valid backup image.
11.Wait until the following message appears:
12.Switch the control off.
13.Withdraw the storage medium from the slot at the front panel of the control.
Service cases - software
3.3 Software backup
Software and hardware
50 Service Manual, 08/2018, 6FC5397-5DP40-6BA1

Siemens SINUMERIK 828D Series Specifications

General

Display	10.4" TFT color display
Operating System	Embedded Linux
Power Supply	24V DC
Protection Class	IP65 (front), IP20 (rear)
Control Unit Type	CNC
Interfaces	Ethernet, USB, RS232
Programming	ShopMill, ShopTurn, G-code
