Service cases - hardware
4.11 Double Motor Modules
Hardware and Software
164 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
9. Reconnect motor connections X1 and X2 - if available - to the module.
10. Insert the DRIVE-CLiQ cables that were previously withdrawn into sockets X200 - X202.
11. Reinsert the enable terminals X21 and X22 - if available - into the module.
12. Check whether all of the cables have been re-connected.
13. Close the cabinet and switch-on the system again.
CAUTION
Ensure that all of the connectors and screws are correctly tightened and latched or
inserted.
WARNING
The components must only be operated when the protective cover of the DC link is closed.
Damaged components must not be used.
