Service cases - software
3.3 Software backup
Hardware and Software
Service Manual, 03/2011, 6FC5397-5DP40-0BA0
43
15. Switch the control on.
16. The control boots normally.
Note
If the procedure is interrupted, then it must be restarted.
If the system CompactFlash Card is no longer identified as a bootable CompactFlash
Card, then a mini boot system must be generated on this card. (See also: This is how you
gene
rate a mini boot system (Page 48) )
In this
case, the license key of the system CompactFlash Card should be transferred to
the control.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
