Siemens SINUMERIK 828D Service Manual

Service cases - software
3.6 Licensing
Hardware and Software
60 Service Manual, 03/2011, 6FC5397-5DP40-0BA0
6. Log on via "Direct access".
Follow additional instructions in the Web License Manager:
7. After completing the assignment process, enter the license key displayed in the Web
License Manager into the "Licensing" dialog box in SINUMERIK Operate.
Note
License key via e-mail
If you have an e-mail address, you have the option (checkbox) of receiving the license
key by e-mail.
Entering the license key
The newly purchased license key is entered into the control.
Procedure:
1. Select the "Start-up" operating area.
2. Press the menu forward key.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
