Siemens SINUMERIK 840D sl Operation/Programming

4
Creating a ShopTurn Program 08/2005
4
♥ Siemens AG, 2005. All rights reserved
4-142 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Teach TC
position
 Press the "Teach TC position" softkey if you want to set the
current position of the tool as a tool change point.
The tool’s coordinates are adopted by the parameters XT and ZT.
 Press the "Accept" softkey.
The work plan is displayed.
ShopTurn has automatically defined the end of the program.

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
