Introduction 08/2005
1.3 O
erator interface
1
♥ Siemens AG, 2005. All rights reserved
1-30 SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition
Secondary mode
REF: Approaching a reference point
REPOS: Repositioning
INC1 ... INC10000: Fixed increment
INC_VAR: Variable increment
Channel status
RESET
Active
Interrupted
Program control
SKP: Skip G code block
DRY: Dry run feedrate
!ROV: Feedrate override only (not feedrate and rapid traverse
override)
SBL1: Single-block (stop after each block that has a function on
the machine)
SBL2: Selection not possible in ShopTurn (stop after each block)
SBL3: Single-block fine (stop after each block, also within a cycle)
M01: Programmed stop
DRF: DRF offset
PRT: Program test
Channel operational
messages
Stop: An operator action is required.
Wait: No operator action is required.
If a dwell time is active, the remaining dwell time is displayed. It is
either displayed in seconds or as spindle revolutions.
Position display of the
axes
The actual value display in the position display refers to the SZS
coordinate system (settable zero system). The position of the active
tool relative to the workpiece zero is displayed.
Symbols for axis displays:
Linear axis clamped
Rotary axis clamped
Feedrate status
Feedrate is not enabled
Spindle status
Spindle is not enabled
Spindle is stationary
Spindle is turning clockwise
Spindle is turning counterclockwise
The display of the spindle utilization as a percentage can be 200 %.
Please refer to the machine manufacturer's instructions.
