Siemens SINUMERIK 840D sl Operation/Programming

11
08/2005 Examples
11.2 Contour millin
g
11
♥ Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 11-423
R 10 abs X 0 abs
Dialog
selection
Dialog
accept
3.
Tangent to
prec. elem.
Direct. of rot.
R 10 abs X 0 abs
Dialog
selection
Dialog
accept
4.
Tangent to
prec. elem.
Direct. of rot.
R 10 abs X 0 abs
Dialog
selection
Dialog
accept
5.
Tangent to
prec. elem.
Direct. of rot.
R 10 abs X 0 abs
Dialog
selection
Dialog
accept
6.
Tangent to
prec. elem.
Direct. of rot.
R 10 abs X 0 abs
Dialog
selection
Dialog
accept
Outside contour
 Press the
softkey

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
