08/2005 Examples

11.2 Contour millin

g

11

♥ Siemens AG, 2005. All rights reserved

SINUMERIK 840D sl Operation/Programming ShopTurn (BAT) – 08/2005 Edition 11-425

3.

Tangent to

prec. elem.

Direct. of rot.

R 14 abs X 0 abs

Dialog

selection

Dialog

accept

4.

Tangent to

prec. elem.

Direct. of rot.

R 6 abs X 0 abs

Dialog

selection

Dialog

accept

5.

Tangent to

prec. elem.

Direct. of rot.

R 14 abs X 0 abs

Dialog

selection

Dialog

accept

6.

Tangent to

prec. elem.

Direct. of rot.

R 6 abs X 0 abs

Dialog

selection

Dialog

accept

Inside contour
