Design of the gas connections
Dimensions of purging gas couplings
Diameter Exterior 12 mm
Length

Without sealing caps 28 mm
With sealing caps 41 mm
8.1.5 Connecting gas
8.1.5.1 Device with analyzer modules, standard version
Procedure
1. Connect the gas lines by means of suitable clamping ring screwed connections to the
associated gas inlets and outlets.
When tightening the union nuts at the screwed connections make sure that you counter
properly.
2. Check the clamping ring screwed connections for a tight 󹪝t and the pipe connections for
leaks.
8.1.5.2 Device with one OXYMAT 7 analyzer module, high-temperature version
Procedure
1. Connect the gas lines by means of suitable clamping ring connections to the associated gas
inlets and outlets.
When tightening the union nuts at the gas connection 󹪝ttings, make sure that you counter
properly.
2. Check whether the clamping ring connections are connected 󹪝rmly and check the pipe
connections for leaks.
Connecting the device
8.1Gas connections
Wall-mounted device
102 Operating Instructions, 07/2023, A5E31930403-AB
