8.2.6 Connecting the power supply
Overview






① Power supply unit ④ Shielding plate
② Appliance plug ⑤ Power supply cable gland
③ Screws for door ⑥ Equipotential bonding
Figure8-12 Wall-mounted device, connecting power supply
Connecting the device
8.2Electrical connections
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 113
