4.5.2 Module structure, high-temperature version




① Sample gas inlet  
② Sample gas outlet  
③ Reference gas outlet  
④ Reference gas inlet  
Figure4-9 Structure of ULTRAMAT 7 high-temperature, gas connections
Description
4.5ULTRAMAT 7
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 33
