Siemens SIPROCESS GA700 Operating Instructions

Electrical characteristics
Electrical safety in accordance with EN61010-1, overvoltage category II
Transient protection It has to be ensured that the transient protection is set to a value that
does not exceed 140% of the measured peak voltage value at the
device power supply connectors.
Power unit cable max. Ø 10 mm (3/0 AWG), max. 3 x 2.1 mm
2
(14 AWG), fuse 10 A (s. IEC
plug)
Table 13-3 Wall housing: Purging gas pressure
Purging gas pressure
Continuous (recommended) 30 hPa above ambient
Continuous (maximum) <100hPa above ambient pressure
Transient (maximum) 165hPa above ambient pressure
Table 13-4 Wall housing: Electrical inputs and outputs
Electrical inputs and outputs
Digital outputs (DO) 8, with changeover contacts, parameters can be freely assigned, e.g. for measuring
range identi󹪝cation;
max. load: 24 V/1.7 A, AC/DC (total load for all 8 relay outputs in continuous operation
max. 160W), isolated, non-sparking
Digital inputs (DI) 8, designed for 24V, isolated, freely parameterizable, e.g. for autoranging
Ethernet interface (bottom) Ethernet RJ 45, 100MBit
Service interface (inside at PU) Ethernet RJ 45, 100MBit
Table 13-5 Wall housing: Option modules
Option modules
Option module 1.1 12 digital outputs, with changeover contacts, max. load: 24 V/1.7 A, AC/DC (total load for
all 12 relay outputs in continuous operation max.244W), isolated, non-sparking
8 digital inputs, designed for 24V, isolated, freely parameterizable
Option module 2.1 6 analog outputs, 0/4to20 mA, designed for 24V, isolated; maximum load 750Ω
6 digital outputs, max. load: 24V/1.7A, AC/DC (total load for all 6 relay outputs in
continuous operation max. 122W), isolated, non-sparking
Option module 2.2 6 analog outputs 0/4to20mA, designed for 24V, isolated; max. load 750Ω
4 analog inputs 0/4 to 20 mA, designed for 24 V, non-isolated, internal resistance 100 Ω
4 digital inputs, designed for 24V, isolated
Table 13-6 Wall housing: Climatic conditions
Climatic conditions
Permissible operating altitude 3000m above sea level
Permissible ambient temperature
during storage and transport
-30...+65°C (-22...149°F)
Technical speci󹪝cations
13.2Technical speci󹪝cations of the wall housing
Wall-mounted device
162 Operating Instructions, 07/2023, A5E31930403-AB
