Siemens SIPROCESS GA700 Operating Instructions

Table 13-20 ULTRAMAT 7: Temperature of sample chamber and gas path
Temperature of sample chamber
and gas path
ULTRAMAT 7 ULTRAMAT 7 high-temperature
1)
Gas path 5K above ambient temperature Stainless steel pipe:
≥ 60 °C (140 °F) with ambient temperature
T
a
= 5 °C (41°F)
≥ 65 °C (149 °F) with ambient temperature
T
a
= 20 °C (68°F)

Hastelloy pipe:
≥ 55 °C (131 °F) with ambient temperature
T
a
= 5 °C (41°F)
≥ 65 °C (149 °F) with ambient temperature
T
a
≥ 25 °C (77°F)
Sample chamber 5K above ambient temperature 65°C (149°F)
1)
The high-temperature version of the analyzer module is not intended for installation in the rack-mounted device.
Table 13-21 ULTRAMAT 7: Time response
Time response
Warm-up period at room temperature <2h
Response characteris‐
tics


Dead time (T
10
) Application-speci󹪝c (max.5s)
Signal rise timeT
r
1)
or signal fall timeT
f
2)
with application-
speci󹪝c electronic damping of 10s
Application speci󹪝c <14s
Time for device-internal signal processing T
v
Approx. 1 s
Delayed display T
90
T
90
< T
10
+ T
r/f
+ T
v
1)
"Risetime"
2)
"Falltime"
Table 13-22 ULTRAMAT 7: Measuring response
Measuring response 
Output signal 󹪞uctuation ≤ ± 1% of smallest measuring range acc. to nameplate
Zero point drift ≤2%/week of smallest measuring range acc. to nameplate
Measured value drift ≤ 1% of the biggest measuring range per week
Repeatability ≤ ± 1% of the current full-scale value
Linearity deviation ≤ 1% of the current full-scale value
Technical speci󹪝cations
13.3Technical speci󹪝cations of analyzer modules
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 169
