If the device is retro󹪝tted with an option module 2.1, this must be activated via LUI or PDM.
Option module 2.2
Option module 2.2 (OM2.2) is a system module connected directly via the CAN bus. Just like the
analyzer modules, this module is an "intelligent" module with the following core properties:
Independent identi󹪝cation in the menu of the LUI
Plug & measure capability
Parameter assignment including parameter block transfer (save and restore)
Diagnostics and test functions
Inclusion in the logbook
Download of 󹪝rmware and parameter blocks
Compared to option module 2.1, the option module 2.2 provides four analog inputs and
four digital inputs. The additional analog inputs can be used as measured value source for
the correction of cross-interference and/or pressure compensation. You can also output the
analog input measured values in the display of the additional process values (main view).
Test mode can be activated for analog as well as digital inputs.
Inputs/outputs of option modules OM2.1 and OM2.2
Table 4-2 Inputs/outputs at a glance
Option module 2.1 Option module 2.2
The option module 2.1 has the following inputs/
outputs:
6 digital outputs (3 digital outputs per analyzer
module): These digital outputs are assigned
󹪝xed to a function
6analog outputs
The option module 2.2 has the following inputs/
outputs:
4 analog inputs
4 digital inputs
6analog outputs
Description
4.7Option modules
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 39
