Siemens SIPROTEC 5 V8.83 User Manual

Plug-In Module
USART-AB-1EL USART-AC-2EL USART-AD-1FO USART-AE-2FO
ETH-BA-2EL
ETH-BB-2FO ETH-BD-2FO
1
ETH-YA-2FO USART-AF-1LDFO USART-AW-2LDFO USART-AG-1LDFO
USART-AU-2LDFO
USART-AK-1LDFO USART-AV-2LDFO USART-AH-1LDFO
2
USART-AJ-1LDFO
3
USART-AX-2LDFO
4
USART-AY-2LDFO
5
ANAI-CA-4EL ARC-CD-3FO
1 x optical serial, bidirectional via 1
common optical fiber, 1550 nm/
1300 nm (Tx/Rx), LC simplex plug, 40
km via 9/125 μm singlemode optical
fiber
3
■
2 x optical serial, bidirectional via
1 common optical fiber, 1300 nm/
1550 nm (Tx/Rx), 2 x LC simplex plug,
40 km via 9/125 μm singlemode optical
fiber
4
■
2 x optical serial, bidirectional via
1 common optical fiber, 1550 nm/
1300 nm (Tx/Rx), 2 x LC simplex plug,
40 km via 9/125 μm singlemode optical
fiber
5
■
8-pin screw-type terminal spring ■
3 x optical (for point sensor) ■
Application
DIGSI 5 protocol ■ ■ ■ ■
IEC 61850-8-1 server
You can find more information
(whether GOOSE or MMS reporting) in
the Communication protocols manual,
chapter IEC 61850.
■ ■ ■ ■
IEC 61850-9-2 Merging Unit ■
IEC 61850-9-2 Process-Bus Client ■
IEC 60870-5-103 ■ ■ ■ ■
IEC 60870-5-104 ■ ■ ■
DNP3 serial ■ ■ ■ ■
DNP3 TCP ■ ■ ■
Modbus TCP ■ ■ ■ ■
Synchrophasor (IEEE C37.118 - PMU) ■ ■ ■
Protection interface (Sync. HDLC) ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
Protection interface (IEEE C37.94) ■ ■
PROFINET IO ■ ■ ■
7
SUP Serial (Slave Unit Protocol) for
connecting external temperature- or
20-mA measuring devices
■ ■ ■ ■
1
For modular devices only (not for 7ST85 and 6MD89)
2
USART-AH-1LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
3
USART-AJ-1LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
4
USART-AX-2LDFO only in connection with USART-AJ-1LDFO or USART-AY-2LDFO
5
USART-AY-2LDFO only in connection with USART-AH-1LDFO or USART-AX-2LDFO
7
PROFINET IO is available in the ETH-BD-2FO module with S2 redundancy and SOE functionality for V8.30 and higher.
Plug-In Modules
4.2 Communication Modules
160 SIPROTEC 5, Hardware Description, Manual
C53000-G5040-C002-M, Edition 12.2021
