A.8 Information List
577
7SA522 Manual
C53000-G1176-C155-3
5237 Frequency protection: f2 TRIP (f2
TRIP)
Frequency Prot. OUT * ON * LED BO 70 235 2 Yes
5238 Frequency protection: f3 TRIP (f3
TRIP)
Frequency Prot. OUT * ON * LED BO 70 236 2 Yes
5239 Frequency protection: f4 TRIP (f4
TRIP)
Frequency Prot. OUT * ON * LED BO 70 237 2 Yes
5240 Frequency protection: TimeOut
Stage f1 (Time Out f1)
Frequency Prot. OUT * * * LED BO
5241 Frequency protection: TimeOut
Stage f2 (Time Out f2)
Frequency Prot. OUT * * * LED BO
5242 Frequency protection: TimeOut
Stage f3 (Time Out f3)
Frequency Prot. OUT * * * LED BO
5243 Frequency protection: TimeOut
Stage f4 (Time Out f4)
Frequency Prot. OUT * * * LED BO
6854 >Trip circuit superv. 1: Trip Relay
(>TripC1 TripRel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6855 >Trip circuit superv. 1: Breaker
Relay (>TripC1 Bkr.Rel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6856 >Trip circuit superv. 2: Trip Relay
(>TripC2 TripRel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6857 >Trip circuit superv. 2: Breaker
Relay (>TripC2 Bkr.Rel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6858 >Trip circuit superv. 3: Trip Relay
(>TripC3 TripRel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6859 >Trip circuit superv. 3: Breaker
Relay (>TripC3 Bkr.Rel)
TripCirc.Superv SP ON
OFF
**LEDBIBO
6861 Trip circuit supervision OFF
(TripC OFF)
TripCirc.Superv OUT ON
OFF
**LEDBO
6865 Failure Trip Circuit (FAIL: Trip
cir.)
TripCirc.Superv OUT ON
OFF
* * LED BO 128 36 1 Yes
6866 TripC1 blocked: Binary input is
not set (TripC1 ProgFAIL)
TripCirc.Superv OUT ON
OFF
**LEDBO
6867 TripC2 blocked: Binary input is
not set (TripC2 ProgFAIL)
TripCirc.Superv OUT ON
OFF
**LEDBO
6868 TripC3 blocked: Binary input is
not set (TripC3 ProgFAIL)
TripCirc.Superv OUT ON
OFF
**LEDBO
7104 >BLOCK Backup OverCurrent
I>> (>BLOCK O/C I>>)
Back-Up O/C SP ON
OFF
* * LED BI BO 64 4 1 Yes
7105 >BLOCK Backup OverCurrent I>
(>BLOCK O/C I>)
Back-Up O/C SP ON
OFF
* * LED BI BO 64 5 1 Yes
7106 >BLOCK Backup OverCurrent Ip
(>BLOCK O/C Ip)
Back-Up O/C SP ON
OFF
* * LED BI BO 64 6 1 Yes
7110 >Backup OverCurrent Instanta-
neousTrip (>O/C InstTRIP)
Back-Up O/C SP ON
OFF
ON
OFF
* LED BI BO 64 10 1 Yes
7130 >BLOCK I-STUB (>BLOCK I-
STUB)
Back-Up O/C SP ON
OFF
**LEDBIBO64301Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Inputs
Function Key
Relay
Chatter suppression
Type
Information Number
Data Unit
General Interrogation
