A.8 Information List
579
7SA522 Manual
C53000-G1176-C155-3
7185 Backup O/C Pickup L123E (O/C
PickupL123E)
Back-Up O/C OUT * ON * LED BO 64 85 2 No
7191 Backup O/C Pickup I>> (O/C
PICKUP I>>)
Back-Up O/C OUT * ON * LED BO 64 91 2 Yes
7192 Backup O/C Pickup I> (O/C
PICKUP I>)
Back-Up O/C OUT * ON * LED BO 64 92 2 Yes
7193 Backup O/C Pickup Ip (O/C
PICKUP Ip)
Back-Up O/C OUT * ON * LED BO 64 93 2 Yes
7201 O/C I-STUB Pickup (I-STUB
PICKUP)
Back-Up O/C OUT * ON
OFF
* LED BO 64 101 2 Yes
7211 Backup O/C General TRIP
command (O/C TRIP)
Back-Up O/C OUT * * * LED BO 128 72 2 No
7212 Backup O/C TRIP - Only L1 (O/C
TRIP 1p.L1)
Back-Up O/C OUT * ON * LED BO 64 112 2 No
7213 Backup O/C TRIP - Only L2 (O/C
TRIP 1p.L2)
Back-Up O/C OUT * ON * LED BO 64 113 2 No
7214 Backup O/C TRIP - Only L3 (O/C
TRIP 1p.L3)
Back-Up O/C OUT * ON * LED BO 64 114 2 No
7215 Backup O/C TRIP Phases L123
(O/C TRIP L123)
Back-Up O/C OUT * ON * LED BO 64 115 2 No
7221 Backup O/C TRIP I>> (O/C TRIP
I>>)
Back-Up O/C OUT * ON * LED BO 64 121 2 No
7222 Backup O/C TRIP I> (O/C TRIP
I>)
Back-Up O/C OUT * ON * LED BO 64 122 2 No
7223 Backup O/C TRIP Ip (O/C TRIP
Ip)
Back-Up O/C OUT * ON * LED BO 64 123 2 No
7235 O/C I-STUB TRIP (I-STUB TRIP) Back-Up O/C OUT * ON * LED BO 64 135 2 No
7325 CB1-TEST TRIP command -
Only L1 (CB1-TESTtrip L1)
Testing OUT ON
OFF
* * LED BO 153 25 2 Yes
7326 CB1-TEST TRIP command -
Only L2 (CB1-TESTtrip L2)
Testing OUT ON
OFF
* * LED BO 153 26 2 Yes
7327 CB1-TEST TRIP command -
Only L3 (CB1-TESTtrip L3)
Testing OUT ON
OFF
* * LED BO 153 27 2 Yes
7328 CB1-TEST TRIP command L123
(CB1-TESTtrip123)
Testing OUT ON
OFF
* * LED BO 153 28 2 Yes
7329 CB1-TEST CLOSE command
(CB1-TEST close)
Testing OUT ON
OFF
* * LED BO 153 29 2 Yes
7345 CB-TEST is in progress (CB-
TEST running)
Testing OUT ON
OFF
* * LED BO 153 45 2 Yes
7346 CB-TEST canceled due to Power
Sys. Fault (CB-TSTstop FLT.)
Testing OUT_
Ev
ON *
7347 CB-TEST canceled due to CB
already OPEN (CB-TSTstop
OPEN)
Testing OUT_
Ev
ON *
7348 CB-TEST canceled due to CB
was NOT READY (CB-TSTstop
NOTr)
Testing OUT_
Ev
ON *
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Inputs
Function Key
Relay
Chatter suppression
Type
Information Number
Data Unit
General Interrogation
