A Appendix
580
7SA522 Manual
C53000-G1176-C155-3
7349 CB-TEST canceled due to CB
stayed CLOSED (CB-TSTstop
CLOS)
Testing OUT_
Ev
ON *
7350 CB-TEST was succesful (CB-
TST .OK.)
Testing OUT_
Ev
ON *
10201 >BLOCK Uph-e>(>) Overvolt.
(phase-earth) (>Uph-e>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10202 >BLOCK Uph-ph>(>) Overvolt
(phase-phase) (>Uph-ph>(>)
BLK)
Voltage Prot. SP * * * LED BI BO
10203 >BLOCK 3U0>(>) Overvolt. (zero
sequence) (>3U0>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10204 >BLOCK U1>(>) Overvolt. (posi-
tive seq.) (>U1>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10205 >BLOCK U2>(>) Overvolt. (neg-
ative seq.) (>U2>(>) BLK)
Voltage Prot. SP * * * LED BI BO
10206 >BLOCK Uph-e<(<) Undervolt
(phase-earth) (>Uph-e<(<) BLK)
Voltage Prot. SP * * * LED BI BO
10207 >BLOCK Uphph<(<) Undervolt
(phase-phase) (>Uphph<(<)
BLK)
Voltage Prot. SP * * * LED BI BO
10208 >BLOCK U1<(<) Undervolt (posi-
tive seq.) (>U1<(<) BLK)
Voltage Prot. SP * * * LED BI BO
10215 Uph-e>(>) Overvolt. is switched
OFF (Uph-e>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73151Yes
10216 Uph-e>(>) Overvolt. is
BLOCKED (Uph-e>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 16 1 Yes
10217 Uph-ph>(>) Overvolt. is switched
OFF (Uph-ph>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73171Yes
10218 Uph-ph>(>) Overvolt. is
BLOCKED (Uph-ph>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 18 1 Yes
10219 3U0>(>) Overvolt. is switched
OFF (3U0>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73191Yes
10220 3U0>(>) Overvolt. is BLOCKED
(3U0>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 20 1 Yes
10221 U1>(>) Overvolt. is switched
OFF (U1>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73211Yes
10222 U1>(>) Overvolt. is BLOCKED
(U1>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 22 1 Yes
10223 U2>(>) Overvolt. is switched
OFF (U2>(>) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73231Yes
10224 U2>(>) Overvolt. is BLOCKED
(U2>(>) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 24 1 Yes
10225 Uph-e<(<) Undervolt. is switched
OFF (Uph-e<(<) OFF)
Voltage Prot. OUT ON
OFF
**LEDBO73251Yes
10226 Uph-e<(<) Undervolt. is
BLOCKED (Uph-e<(<) BLK)
Voltage Prot. OUT ON
OFF
ON
OFF
* LED BO 73 26 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Inputs
Function Key
Relay
Chatter suppression
Type
Information Number
Data Unit
General Interrogation
