A.10 Measured Values
587
7SA522 Manual
C53000-G1176-C155-3
869 U L23 Maximum (UL23Max=) Min/Max meter - - - - - CFC CD DD
870 U L31 Minimum (UL31Min=) Min/Max meter - - - - - CFC CD DD
871 U L31 Maximum (UL31Min=) Min/Max meter - - - - - CFC CD DD
874 U1 (positive sequence) Voltage Minimum (U1
Min =)
Min/Max meter - - - - - CFC CD DD
875 U1 (positive sequence) Voltage Maximum
(U1 Max =)
Min/Max meter - - - - - CFC CD DD
880 Apparent Power Minimum (SMin=) Min/Max meter - - - - - CFC CD DD
881 Apparent Power Maximum (SMax=) Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fMin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fMax=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy - - - - - CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy - - - - - CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CD DD
924 Wp Forward (Wp+=) Energy - - - - - CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CD DD
925 Wq Forward (Wq+=) Energy - - - - - CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CD DD
928 Wp Reverse (Wp-=) Energy - - - - - CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CD DD
929 Wq Reverse (Wq-=) Energy - - - - - CD DD
963 I L1 demand (IL1dmd=) Demand meter - - - - - CFC CD DD
964 I L2 demand (IL2dmd=) Demand meter - - - - - CFC CD DD
965 I L3 demand (IL3dmd=) Demand meter - - - - - CFC CD DD
966 R L1E (R L1E=) Measurement - - - - - CFC CD DD
967 R L2E (R L2E=) Measurement - - - - - CFC CD DD
970 R L3E (R L3E=) Measurement - - - - - CFC CD DD
971 R L12 (R L12=) Measurement - - - - - CFC CD DD
972 R L23 (R L23=) Measurement - - - - - CFC CD DD
973 R L31 (R L31=) Measurement - - - - - CFC CD DD
974 X L1E (X L1E=) Measurement - - - - - CFC CD DD
975 X L2E (X L2E=) Measurement - - - - - CFC CD DD
976 X L3E (X L3E=) Measurement - - - - - CFC CD DD
977 X L12 (X L12=) Measurement - - - - - CFC CD DD
978 X L23 (X L23=) Measurement - - - - - CFC CD DD
979 X L31 (X L31=) Measurement - - - - - CFC CD DD
1040 Active Power Minimum Forward (Pmin
Forw=)
Min/Max meter - - - - - CFC CD DD
1041 Active Power Maximum Forward (Pmax
Forw=)
Min/Max meter - - - - - CFC CD DD
1042 Active Power Minimum Reverse (Pmin Rev
=)
Min/Max meter - - - - - CFC CD DD
1043 Active Power Maximum Reverse (Pmax Rev
=)
Min/Max meter - - - - - CFC CD DD
1044 Reactive Power Minimum Forward (Qmin
Forw=)
Min/Max meter - - - - - CFC CD DD
1045 Reactive Power Maximum Forward (Qmax
Forw=)
Min/Max meter - - - - - CFC CD DD
1046 Reactive Power Minimum Reverse (Qmin
Rev =)
Min/Max meter - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
