Siemens siprotec 7SA522 User Manual

A Appendix
588
7SA522 Manual
C53000-G1176-C155-3
1047 Reactive Power Maximum Reverse (Qmax
Rev =)
Min/Max meter - - - - - CFC CD DD
1048 Power Factor Minimum Forward (PFmin-
Forw=)
Min/Max meter - - - - - CFC CD DD
1049 Power Factor Maximum Forward (PFmax-
Forw=)
Min/Max meter - - - - - CFC CD DD
1050 Power Factor Minimum Reverse (PFmin
Rev=)
Min/Max meter - - - - - CFC CD DD
1051 Power Factor Maximum Reverse (PFmax
Rev=)
Min/Max meter - - - - - CFC CD DD
1052 Active Power Demand Forward (Pdmd
Forw=)
Demand meter - - - - - CFC CD DD
1053 Active Power Demand Reverse (Pdmd Rev
=)
Demand meter - - - - - CFC CD DD
1054 Reactive Power Demand Forward (Qdmd
Forw=)
Demand meter - - - - - CFC CD DD
1055 Reactive Power Demand Reverse (Qdmd
Rev =)
Demand meter - - - - - CFC CD DD
7751 Prot Int 1:Transmission delay (PI1 TD) Statistics - - - - - CFC CD DD
7752 Prot Int 2:Transmission delay (PI2 TD) Statistics - - - - - CFC CD DD
7753 Prot Int 1: Availability per min. (PI1A/m) Statistics - - - - - CFC CD DD
7754 Prot Int 1: Availability per hour (PI1A/h) Statistics - - - - - CFC CD DD
7755 Prot Int 2: Availability per min. (PI2A/m) Statistics - - - - - CFC CD DD
7756 Prot Int 2: Availability per hour (PI2A/h) Statistics - - - - - CFC CD DD
7757 Prot Int 1: DTOG (Device Time Offset) (PI1
DTOG)
Statistics - - - - - CFC CD DD
7758 Prot Int 2: DTOG (Device Time Offset) (PI2
DTOG)
Statistics - - - - - CFC CD DD
7761 Relay ID of 1. relay (Relay ID) Measure relay1 - - - - - CFC CD DD
7781 Relay ID of 2. relay (Relay ID) Measure relay2 - - - - - CFC CD DD
7801 Relay ID of 3. relay (Relay ID) Measure relay3 - - - - - CFC CD DD
10102 Min. Zero Sequence Voltage 3U0 (3U0min
=)
Min/Max meter - - - - - CFC CD DD
10103 Max. Zero Sequence Voltage 3U0 (3U0max
=)
Min/Max meter - - - - - CFC CD DD
14000 IL1 (primary) (IL1 =) Measure relay1 - - - - - CFC CD DD
14001 Angle IL1 (ϕIL1 =) Measure relay1 - - - - - CFC CD DD
14002 IL2 (primary) (IL2 =) Measure relay1 - - - - - CFC CD DD
14003 Angle IL2 (ϕIL2 =) Measure relay1 - - - - - CFC CD DD
14004 IL3 (primary) (IL3 =) Measure relay1 - - - - - CFC CD DD
14005 Angle IL3 (ϕIL3 =) Measure relay1 - - - - - CFC CD DD
14010 UL1E (primary) (UL1E =) Measure relay1 - - - - - CFC CD DD
14011 Angle UL1E (ϕUL1E =) Measure relay1 - - - - - CFC CD DD
14012 UL2E (primary) (UL2E =) Measure relay1 - - - - - CFC CD DD
14013 Angle UL2E (ϕUL2E =) Measure relay1 - - - - - CFC CD DD
14014 UL3E (primary) (UL3E =) Measure relay1 - - - - - CFC CD DD
14015 Angle UL3E (ϕUL3E =) Measure relay1 - - - - - CFC CD DD
14020 IL1 (primary) (IL1 =) Measure relay2 - - - - - CFC CD DD
14021 Angle IL1 (ϕIL1 =) Measure relay2 - - - - - CFC CD DD
14022 IL2 (primary) (IL2 =) Measure relay2 - - - - - CFC CD DD
14023 Angle IL2 (ϕIL2 =) Measure relay2 - - - - - CFC CD DD
14024 IL3 (primary) (IL3 =) Measure relay2 - - - - - CFC CD DD
14025 Angle IL3 (ϕIL3 =) Measure relay2 - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
