A.10 Measured Values
589
7SA522 Manual
C53000-G1176-C155-3
■
14030 UL1E (primary) (UL1E =) Measure relay2 - - - - - CFC CD DD
14031 Angle UL1E (ϕUL1E =) Measure relay2 - - - - - CFC CD DD
14032 UL2E (primary) (UL2E =) Measure relay2 - - - - - CFC CD DD
14033 Angle UL2E (ϕUL2E =) Measure relay2 - - - - - CFC CD DD
14034 UL3E (primary) (UL3E =) Measure relay2 - - - - - CFC CD DD
14035 Angle UL3E (ϕUL3E =) Measure relay2 - - - - - CFC CD DD
14040 IL1 (primary) (IL1 =) Measure relay3 - - - - - CFC CD DD
14041 Angle IL1 (ϕIL1 =) Measure relay3 - - - - - CFC CD DD
14042 IL2 (primary) (IL2 =) Measure relay3 - - - - - CFC CD DD
14043 Angle IL2 (ϕIL2 =) Measure relay3 - - - - - CFC CD DD
14044 IL3 (primary) (IL3 =) Measure relay3 - - - - - CFC CD DD
14045 Angle IL3 (ϕIL3 =) Measure relay3 - - - - - CFC CD DD
14050 UL1E (primary) (UL1E =) Measure relay3 - - - - - CFC CD DD
14051 Angle UL1E (ϕUL1E =) Measure relay3 - - - - - CFC CD DD
14052 UL2E (primary) (UL2E =) Measure relay3 - - - - - CFC CD DD
14053 Angle UL2E (ϕUL2E =) Measure relay3 - - - - - CFC CD DD
14054 UL3E (primary) (UL3E =) Measure relay3 - - - - - CFC CD DD
14055 Angle UL3E (ϕUL3E =) Measure relay3 - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
