Siemens SIPROTEC 7SK80 User Manual

Functions
2.13 Flexible Protection Functions
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
216
0 P.U. THRESHOLD 0.05 .. 40.00 A 2.00 A Pickup Threshold
0 P.U. THRESHOLD 1A 0.05 .. 40.00 A 2.00 A Pickup Threshold
5A 0.25 .. 200.00 A 10.00 A
0 P.U. THRESHOLD 1A 0.001 .. 1.500 A 0.100 A Pickup Threshold
5A 0.005 .. 7.500 A 0.500 A
0 P.U. THRESHOLD 2.0 .. 260.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD 2.0 .. 200.0 V 110.0 V Pickup Threshold
0 P.U. THRESHOLD 40.00 .. 60.00 Hz 51.00 Hz Pickup Threshold
0 P.U. THRESHOLD 50.00 .. 70.00 Hz 61.00 Hz Pickup Threshold
0 P.U. THRESHOLD 0.10 .. 20.00 Hz/s 5.00 Hz/s Pickup Threshold
0 P.U. THRESHOLD 1A 2.0 .. 10000.0 W 200.0 W Pickup Threshold
5A 10.0 .. 50000.0 W 1000.0 W
0 P.U. THRESHOLD -0.99 .. 0.99 0.50 Pickup Threshold
0 P.U. THRESHOLD 15 .. 100 % 20 % Pickup Threshold
0 P.U. THRESHOLD 2.0 .. 260.0 V 110.0 V Pickup Threshold
0 T TRIP DELAY 0.00 .. 3600.00 sec 1.00 sec Trip Time Delay
0A T PICKUP DELAY 0.00 .. 60.00 sec 0.00 sec Pickup Time Delay
0 T PICKUP DELAY 0.00 .. 28800.00 sec 0.00 sec Pickup Time Delay
0A T DROPOUT DELAY 0.00 .. 60.00 sec 0.00 sec Dropout Time Delay
0A BLK.by Vol.Loss NO
YES
YES Block in case of Meas.-
Voltage Loss
0A DROPOUT RATIO 0.70 .. 0.99 0.95 Dropout Ratio
0A DROPOUT RATIO 1.01 .. 3.00 1.05 Dropout Ratio
0 DO differential 0.02 .. 1.00 Hz 0.03 Hz Dropout differential
Addr. Parameter C Setting Options Default Setting Comments
