Appendix
A.11 Measured Values
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
469
A.11 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Number of TRIPs= (#of TRIPs=) Statistics - - - - - CFC
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CFC
601 Ia (Ia =) Measurement 134 157 No 9 1 CFC
602 Ib (Ib =) Measurement 160 145 Yes 3 1 CFC
134 157 No 9 2
603 Ic (Ic =) Measurement 134 157 No 9 3 CFC
604 In (In =) Measurement 134 157 No 9 4 CFC
605 I1 (positive sequence) (I1 =) Measurement - - - - - CFC
606 I2 (negative sequence) (I2 =) Measurement - - - - - CFC
621 Va (Va =) Measurement 134 157 No 9 6 CFC
622 Vb (Vb =) Measurement 134 157 No 9 7 CFC
623 Vc (Vc =) Measurement 134 157 No 9 8 CFC
624 Va-b (Va-b=) Measurement 160 145 Yes 3 2 CFC
134 157 No 9 9
625 Vb-c (Vb-c=) Measurement 134 157 No 9 10 CFC
626 Vc-a (Vc-a=) Measurement 134 157 No 9 11 CFC
627 VN (VN =) Measurement 134 118 No 9 1 CFC
629 V1 (positive sequence) (V1 =) Measurement - - - - - CFC
630 V2 (negative sequence) (V2 =) Measurement - - - - - CFC
641 P (active power) (P =) Measurement 134 157 No 9 12 CFC
642 Q (reactive power) (Q =) Measurement 134 157 No 9 13 CFC
644 Frequency (Freq=) Measurement 134 157 No 9 5 CFC
645 S (apparent power) (S =) Measurement - - - - - CFC
661 Threshold of Restart Inhibit (Θ REST. =) Measurement - - - - - CFC
680 Angle Va-Ia (Phi A =) Measurement - - - - - CFC
681 Angle Vb-Ib (Phi B =) Measurement - - - - - CFC
682 Angle Vc-Ic (Phi C =) Measurement - - - - - CFC
701 Resistive ground current in isol systems (INs
Real)
Measurement 134 157 No 9 15 CFC
702 Reactive ground current in isol systems (INs
Reac)
Measurement 134 157 No 9 16 CFC
805 Temperature of Rotor (Θ Rotor) Measurement - - - - - CFC
807 Thermal Overload (Θ/Θtrip) Measurement - - - - - CFC
809 Time untill release of reclose-blocking (T re-
close=)
Measurement - - - - - CFC
830 INs Senstive Ground Fault Current (INs =) Measurement 134 118 No 9 3 CFC
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC
832 Vo (zero sequence) (Vo =) Measurement 134 118 No 9 2 CFC
833 I1 (positive sequence) Demand (I1 dmd=) Demand meter - - - - - CFC
834 Active Power Demand (P dmd =) Demand meter - - - - - CFC
835 Reactive Power Demand (Q dmd =) Demand meter - - - - - CFC
836 Apparent Power Demand (S dmd =) Demand meter - - - - - CFC
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CFC
838 I A Demand Maximum (IAdmdMax) Min/Max meter - - - - - CFC
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CFC
