Siemens SIPROTEC 7SK80 User Manual

Appendix
A.11 Measured Values
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
470
840 I B Demand Maximum (IBdmdMax) Min/Max meter - - - - - CFC
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CFC
842 I C Demand Maximum (ICdmdMax) Min/Max meter - - - - - CFC
843 I1 (positive sequence) Demand Minimum
(I1dmdMin)
Min/Max meter - - - - - CFC
844 I1 (positive sequence) Demand Maximum
(I1dmdMax)
Min/Max meter - - - - - CFC
845 Active Power Demand Minimum (PdMin=) Min/Max meter - - - - - CFC
846 Active Power Demand Maximum (PdMax=) Min/Max meter - - - - - CFC
847 Reactive Power Minimum (QdMin=) Min/Max meter - - - - - CFC
848 Reactive Power Maximum (QdMax=) Min/Max meter - - - - - CFC
849 Apparent Power Minimum (SdMin=) Min/Max meter - - - - - CFC
850 Apparent Power Maximum (SdMax=) Min/Max meter - - - - - CFC
851 Ia Min (Ia Min=) Min/Max meter - - - - - CFC
852 Ia Max (Ia Max=) Min/Max meter - - - - - CFC
853 Ib Min (Ib Min=) Min/Max meter - - - - - CFC
854 Ib Max (Ib Max=) Min/Max meter - - - - - CFC
855 Ic Min (Ic Min=) Min/Max meter - - - - - CFC
856 Ic Max (Ic Max=) Min/Max meter - - - - - CFC
857 I1 (positive sequence) Minimum (I1 Min=) Min/Max meter - - - - - CFC
858 I1 (positive sequence) Maximum (I1 Max=) Min/Max meter - - - - - CFC
859 Va-n Min (Va-nMin=) Min/Max meter - - - - - CFC
860 Va-n Max (Va-nMax=) Min/Max meter - - - - - CFC
861 Vb-n Min (Vb-nMin=) Min/Max meter - - - - - CFC
862 Vb-n Max (Vb-nMax=) Min/Max meter - - - - - CFC
863 Vc-n Min (Vc-nMin=) Min/Max meter - - - - - CFC
864 Vc-n Max (Vc-nMax=) Min/Max meter - - - - - CFC
865 Va-b Min (Va-bMin=) Min/Max meter - - - - - CFC
867 Va-b Max (Va-bMax=) Min/Max meter - - - - - CFC
868 Vb-c Min (Vb-cMin=) Min/Max meter - - - - - CFC
869 Vb-c Max (Vb-cMax=) Min/Max meter - - - - - CFC
870 Vc-a Min (Vc-aMin=) Min/Max meter - - - - - CFC
871 Vc-a Max (Vc-aMax=) Min/Max meter - - - - - CFC
872 V neutral Min (Vn Min =) Min/Max meter - - - - - CFC
873 V neutral Max (Vn Max =) Min/Max meter - - - - - CFC
874 V1 (positive sequence) Voltage Minimum (V1
Min =)
Min/Max meter - - - - - CFC
875 V1 (positive sequence) Voltage Maximum
(V1 Max =)
Min/Max meter - - - - - CFC
876 Active Power Minimum (Pmin=) Min/Max meter - - - - - CFC
877 Active Power Maximum (Pmax=) Min/Max meter - - - - - CFC
878 Reactive Power Minimum (Qmin=) Min/Max meter - - - - - CFC
879 Reactive Power Maximum (Qmax=) Min/Max meter - - - - - CFC
880 Apparent Power Minimum (Smin=) Min/Max meter - - - - - CFC
881 Apparent Power Maximum (Smax=) Min/Max meter - - - - - CFC
882 Frequency Minimum (fmin=) Min/Max meter - - - - - CFC
883 Frequency Maximum (fmax=) Min/Max meter - - - - - CFC
884 Power Factor Maximum (PF Max=) Min/Max meter - - - - - CFC
885 Power Factor Minimum (PF Min=) Min/Max meter - - - - - CFC
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
