Siemens SIPROTEC 7SK80 User Manual

Functions
2.3 Directional Gound Overcurrent Protection 67N
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
93
2.3.11 Information List
1621A 67N-1 MEASUREM. Fundamental
True RMS
Fundamental 67N-1 measurement of
1622A 67N-TOC MEASUR. Fundamental
True RMS
Fundamental 67N-TOC measurement of
No. Information Type of In-
formation
Comments
2614 >BLK 67N/67NTOC SP >BLOCK 67N/67N-TOC
2616 >BLOCK 67N-2 SP >BLOCK 67N-2
2623 >BLOCK 67N-1 SP >BLOCK 67N-1
2624 >BLOCK 67N-TOC SP >BLOCK 67N-TOC
2635 Ground forward OUT Ground forward
2636 Ground reverse OUT Ground reverse
2646 67N-2 picked up OUT 67N-2 picked up
2648 67N-2 Time Out OUT 67N-2 Time Out
2656 67N OFF OUT 67N/67N-TOC switched OFF
2657 67N BLOCKED OUT 67N/67N-TOC is BLOCKED
2658 67N ACTIVE OUT 67N/67N-TOC is ACTIVE
2659 67N-1 BLOCKED OUT 67N-1 is BLOCKED
2668 67N-2 BLOCKED OUT 67N-2 is BLOCKED
2677 67N-TOC BLOCKED OUT 67N-TOC is BLOCKED
2679 67N-2 TRIP OUT 67N-2 TRIP
2681 67N-1 picked up OUT 67N-1 picked up
2682 67N-1 Time Out OUT 67N-1 Time Out
2683 67N-1 TRIP OUT 67N-1 TRIP
2684 67N-TOCPickedup OUT 67N-TOC picked up
2685 67N-TOC TimeOut OUT 67N-TOC Time Out
2686 67N-TOC TRIP OUT 67N-TOC TRIP
2687 67N-TOC Disk PU OUT 67N-TOC disk emulation is ACTIVE
2691 67/67N pickedup OUT 67/67N picked up
2695 67N picked up OUT 67N/67N-TOC picked up
2696 67/67N TRIP OUT 67/67N TRIP
