Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
400
A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 7SK80 V4.6
Multifunctional
protection device
with control
6 7 8 9 10 11 12 13 14 15 16 Supplemen-
tary
7SK80 ––H+
Number of binary inputs and outputs Pos. 6
Housing 1/6 19” 4 x I, 3 BI, 5 BO (2 changeover contacts), 1 life status contact 1
Housing 1/6 19” 4 x I, 7 BI, 8 BO (2 changeover contacts), 1 life status contact 2
Housing 1/6 19” 4 x I, 3x V, 3 BI, 5 BO (2 changeover contacts), 1 life status contact 3
Housing 1/6 19” 4 x I, 3x V, 7 BI, 8 BO (2 changeover contacts), 1 life status contact 4
Housing 1/6 19” 4 x I, 3 BI, 5 BO (2 changeover contacts), 5 temperature sensors, 1 life status contact 5
Housing 1/6 19” 4 x I, 3x V, 3 BI, 5 BO (2 changeover contacts), 5 temperature sensors, 1 life status contact 6
Measuring inputs (4 x I)Pos. 7
I
ph
= 1 A, I
n
= 1 A / 5 A 1
I
ph
= 1 A, I
ns
(sensitive) = 0.001 to 1.6 A / 0.005 to 8 A 2
Auxiliary voltage (power supply, pilot voltage) Pos. 8
DC 24 V / 48 V 1
DC 60 V / 110 V / 125 V / 220 V / 250 V, AC 115 V, AC 230 V 5
Construction Pos. 9
Surface-mounted housing, screw-type terminals B
Flush mounting case, screw-type terminals E
Region-specific default settings / function versions and language default settings Pos. 10
Region DE, IEC, language German (language can be changed, standard front panel A
Region world, IEC/ANSI, language English (language can be changed), standard front panel B
Region US, ANSI, language US-English (language can be changed), US front panel C
Region FR, IEC/ANSI, language French (language can be changed), standard front panel D
Region world, IEC/ANSI, language Spanish (language can be changed), standard front panel E
Region world, IEC/ANSI, language Italian (language can be changed), standard front panel F
Region RUS, IEC/ANSI, language Russian (language can be changed), standard front panel G
Region CHN, IEC/ANSI, language Chinese (language can not be changed), chinese front panel K
