Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
401
1)
The converter requires an operating voltage of 24 V DC. If the available operating voltage is > 24 V DC the
additional power supply 7XV5810–0BA00 is required.
Port B (bottom side of device, rear) Pos. 11
not equipped 0
IEC60870-5-103 or DIGSI4/Modem, electrical RS232 1
IEC60870-5-103 or DIGSI4/Modem or RTD box-connection, electrical RS485 2
IEC60870-5-103 or DIGSI4/Modem or RTD box-connection, optical 820nm, ST connector 3
For further interface options see Additional Information in the following 9
Additional information for additional ports (bottom side of device, rear, port B) Supple-
mentary
Profibus DP Slave, electrical RS485 + L 0 A
Profibus DP Slave, 820 nm, optical double ring, ST connector + L 0 B
Modbus, electrical RS485 + L 0 D
Modbus, optical 820 nm, ST connector + L 0 E
DNP3.0, electrical RS485 + L 0 G
DNP3.0, optical 820 nm, ST connector + L 0 H
IEC 60870-5-103 Protocol, redundant, electrical RS485, RJ45 connector + L 0 P
IEC 61850, 100Mbit Ethernet electrical, double, RJ45 connector + L 0 R
IEC 61850 100 Mbit Ethernet optical, double, LC connector duplex + L 0 S
Converter Order number Use
SIEMENS OLM
1)
6GK1502–2CB10 for single ring
SIEMENS OLM
1)
6GK1502–3CB10 for twin ring
Port A (bottom side of device, front) Pos. 12
not equipped 0
with Ethernet port (DIGSI port, RTD box connection, not IEC61850), RJ45 connector 6
Measurement / Fault Recording Pos. 13
With fault recording 1
With fault recording, average values, min/max values 3
