Functions
2.15 Temperature Detection via RTD Boxes
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
231
2.15.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under "Display Additional Settings".
Addr. Parameter Setting Options Default Setting Comments
9000 UDP Port 0 .. 65535 5000 UDP service port in the RTD box
9001 IP address[0] 0 .. 255 0 IP address[0] of RTD box,
connec. by UDP
9002 IP address[1] 0 .. 255 0 IP address[1] of RTD box,
connec. by UDP
9003 IP address[2] 0 .. 255 0 IP address[2] of RTD box,
connec. by UDP
9004 IP address[3] 0 .. 255 0 IP address[3] of RTD box,
connec. by UDP
9005 UDP Port 0 .. 65535 5000 UDP service port in the RTD box
9006 IP address[0] 0 .. 255 0 IP address[0] of RTD box,
connec. by UDP
9007 IP address[1] 0 .. 255 0 IP address[1] of RTD box,
connec. by UDP
9008 IP address[2] 0 .. 255 0 IP address[2] of RTD box,
connec. by UDP
9009 IP address[3] 0 .. 255 0 IP address[3] of RTD box,
connec. by UDP
9011A RTD 1 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Pt 100 Ω RTD 1: Type
9012A RTD 1 LOCATION Oil
Ambient
Winding
Bearing
Other
Oil RTD 1: Location
9013 RTD 1 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 1: Temperature Stage 1
Pickup
9014 RTD 1 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 1: Temperature Stage 1
Pickup
9015 RTD 1 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 1: Temperature Stage 2
Pickup
9016 RTD 1 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 1: Temperature Stage 2
Pickup
9021A RTD 2 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 2: Type
9022A RTD 2 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 2: Location
