Siemens SIPROTEC 7SK80 User Manual

Appendix
A.7 Functional Scope
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
434
A.7 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 OSC. FAULT REC. Disabled
Enabled
Enabled Oscillographic Fault Records
112 Charac. Phase Disabled
Definite Time
TOC IEC
TOC ANSI
Definite Time 50/51
113 Charac. Ground Disabled
Definite Time
TOC IEC
TOC ANSI
Definite Time 50N/51N
116 67N/67N-TOC Disabled
Definite Time
TOC IEC
TOC ANSI
Definite Time 67N, 67N-TOC
117 Coldload Pickup Disabled
Enabled
Disabled Cold Load Pickup
122 InrushRestraint Disabled
Enabled
Disabled 2nd Harmonic Inrush Restraint
130 S.Gnd.F.Dir.Ch cos ϕ / sin ϕ
V0/I0 ϕ mea.
cos ϕ / sin ϕ (sens.) Ground fault dir. character-
istic
131 Sens. Gnd Fault Disabled
Definite Time
User Defined PU
Disabled (sensitive) Ground fault
140 46 Disabled
TOC ANSI
TOC IEC
Definite Time
Disabled 46 Negative Sequence Protection
141 48 Disabled
Enabled
Enabled 48 Startup Time Supervision for
Motors
142 49 Disabled
No ambient temp
With amb. temp.
No ambient temp 49 Thermal Overload Protection
143 66 #of Starts Disabled
Enabled
Enabled 66 Startup Counter for Motors
144 Load Jam Prot. Disabled
Enabled
Enabled Load Jam Protection
150 27/59 Disabled
Enabled
Disabled 27, 59 Under/Overvoltage Protec-
tion
154 81 O/U Disabled
Enabled
Disabled 81 Over/Underfrequency Protec-
tion
170 50BF Disabled
Enabled
enabled w/ 3I0>
Disabled 50BF Breaker Failure Protection
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
