Page #53 background imageLoading...
Page #53 background image
Functions
2.1 General
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
53
2.1.7 EN100-Module
2.1.7.1 Functional Description
The EN100-Module enables integration of the 7SK80 in 100-Mbit communication networks in control and au-
tomation systems with the protocols according to IEC 61850 standard. This standard permits uniform commu-
nication of the devices without gateways and protocol converters. Even when installed in heterogeneous envi-
ronments, SIPROTEC 4 relays therefore provide for open and interoperable operation. Parallel to the process
control integration of the device, this interface can also be used for communication with DIGSI and for inter-
relay communication via GOOSE.
2.1.7.2 Information List
No. Information Type of In-
formation
Comments
009.0100 Failure Modul IntSP Failure EN100 Modul
009.0101 Fail Ch1 IntSP Failure EN100 Link Channel 1 (Ch1)
009.0102 Fail Ch2 IntSP Failure EN100 Link Channel 2 (Ch2)
