Siemens SIPROTEC 7SK80 User Manual

Appendix
A.10 Group Alarms
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
468
A.10 Group Alarms
No. Description Function No. Description
140 Error Sum Alarm 177
178
10080
10081
10082
10083
191
193
Fail Battery
I/O-Board error
Error Ext I/O
Error Ethernet
Error Terminal
Error Basic I/O
Error Offset
Alarm NO calibr
160 Alarm Sum Event 162
163
167
175
176
264
267
208
Failure Σ I
Fail I balance
Fail V balance
Fail Ph. Seq. I
Fail Ph. Seq. V
Fail: RTD-Box 1
Fail: RTD-Box 2
Fail: RTD int.
161 Fail I Superv. 162
163
Failure Σ I
Fail I balance
171 Fail Ph. Seq. 175
176
Fail Ph. Seq. I
Fail Ph. Seq. V
501 Relay PICKUP 1517
5159
5165
5166
-
-
-
6821
10025
1761
2691
1224
1221
1215
49 Winding O/L
46-2 picked up
46-1 picked up
46-TOC pickedup
-
-
-
48 TRIP
Load Jam pickup
50(N)/51(N) PU
67/67N pickedup
50Ns-1 Pickup
50Ns-2 Pickup
64 Pickup
511 Relay TRIP 1521
5170
-
-
-
6821
10026
1791
2696
1226
1223
1217
49 Th O/L TRIP
46 TRIP
-
-
-
48 TRIP
Load Jam TRIP
50(N)/51(N)TRIP
67/67N TRIP
50Ns-1 TRIP
50Ns-2 TRIP
64 TRIP
