Siemens SIPROTEC 7SK80 User Manual

Functions
2.1 General
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
47
2.1.3.4 Information List
263 OP.CYCLES Isc 1 .. 1000 50 Switch. Cycles at Rated
Short-Cir. Curr.
264 Ix EXPONENT 1.0 .. 3.0 2.0 Exponent for the Ix-Method
265 Cmd.via control (Setting options depend
on configuration)
None 52 B.Wear: Open Cmd. via
Control Device
266 T 52 BREAKTIME 1 .. 600 ms 80 ms Breaktime (52 Breaker)
267 T 52 OPENING 1 .. 500 ms 65 ms Opening Time (52 Breaker)
276 TEMP. UNIT Celsius
Fahrenheit
Celsius Unit of temperature mea-
surement
280 Holmgr. for ΣiNO
YES
NO Holmgreen-conn. (for fast
sum-i-monit.)
613A Gnd O/Cprot. w. Ignd (measured)
3I0 (calcul.)
Ignd (measured) Ground Overcurrent protec-
tion with
614A OP. QUANTITY 59 Vphph
Vph-n
V1
V2
Vphph Opera. Quantity for 59 Ov-
ervolt. Prot.
615A OP. QUANTITY 27 V1
Vphph
Vph-n
V1 Opera. Quantity for 27 Und-
ervolt. Prot.
No. Information Type of In-
formation
Comments
5145 >Reverse Rot. SP >Reverse Phase Rotation
5147 Rotation ABC OUT Phase rotation ABC
5148 Rotation ACB OUT Phase rotation ACB
10036 Capac.Par.Fail. OUT Malparameteriz. Volt.-divider Capacities
Addr. Parameter C Setting Options Default Setting Comments
