Siemens SIPROTEC 7SK80 User Manual

Appendix
A.5 Default Settings
SIPROTEC, 7SK80, Manual
E50417-G1140-C344-A4, Release date 08.2010
429
A.5.3 Binary Output
Table A-9 Output Relay Presettings for All Devices and Ordering Variants
Table A-10 Further Output Relay Presettings for 7SK802* or 7SK804*
A.5.4 Function Keys
Table A-11 Applies to All Devices and Ordered Variants
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
BO3 52Breaker 52 Breaker
BO4 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail V balance 167 Failure: Voltage Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
Fail Ph. Seq. V
VT brk. wire
176
253
Failure: Phase Sequence Voltage
Failure VT circuit: broken wire
BO5 Relay PICKUP 501 Relay PICKUP
Binary Output Default function Function No. Description
BO6 not pre-assigned - -
BO7 not pre-assigned - -
BO8 not pre-assigned - -
Function Keys Default function
F1 Display of the operational indications
F2 Display of the primary operational measured values
F3 Display of the last fault log buffer
F4 not pre-assigned
F5 not pre-assigned
F6 not pre-assigned
F7 not pre-assigned
F8 not pre-assigned
F9 not pre-assigned
